HENSOTHERM 471 KS R15-R180
What is this product?
Water-based fire protection for structural steel up to R180
HENSOTHERM 471 KS is a water-based, single-component intumescent coating for structural steel. It is maintenance-free and approved in accordance with BS 476, Certifire No. CF 5344, with fire resistance from R15 to R180 for open and hollow sections.
Where it is used
- I and H sections (girders, compression members, columns)
- Circular and square hollow sections (compression members, columns)
- Box sections (girders, supports)
- Galvanised steel, with a suitable primer
- Up to R180 without a top coat in dry indoor conditions
Product characteristics
- Free of halogens, APEO, borates, plasticisers and silicones
- VOC emission class A+, LEED v4 compliant
- Environmental Product Declaration EPD-RHG-20240229-IAA3-EN
- Up to 1,000 g/m² in a single coat
- Top coats available in RAL and DB shades or to an individual colour sample
Technical data
- Maximum per coat: 1,000 g/m² (approx. 500 µm dry)
- First coat when building up in several coats: max. 700 g/m² (approx. 350 µm dry)
- At least 24 hours per coat at +20°C and 65% relative humidity, overcoat after a positive fingernail test
- Airless spray: 200 to 250 bar, nozzle 0.017 to 0.025 inch, output above 4 l/min, thin with max. 3% water
- Brush or roller: lambskin roller or long-bristled Chinex brush
- Material, substrate and air at least +5°C, relative humidity max. 80%, steel at least 5°C above dew point
- For application by trained personnel
- Supplied in 25 kg plastic buckets
Documents
-
R15 to R180 to BS 476, Certifire CF 5344
-
Water-based, VOC emission class A+
-
Free of halogens, APEO, borates, plasticisers and silicones
-
Up to 1,000 g/m² in a single coat
-
Environmental Product Declaration EPD-RHG-20240229-IAA3-EN
-
LEED v4 compliant
Specifications & Documents
Full technical data and downloadable certification for compliance records.
| Use | Indoor |
| Application Method | Airless spray (200 to 250 bar, nozzle 0.017 to 0.025 inch), lambskin roller or brush |
| Fire Classification | R15 to R180 for open and hollow sections |
| British Standard | BS 476 (Certifire CF 5344) |
| VOC Content | VOC emission class A+ |
| Shelf Life | 12 months unopened |
How to Apply
Simple application with standard tools — no specialist equipment required.
-
1Prime steel before HENSOTHERM 471 KSBlasted steel (Sa 2.5): HENSOGRUND WB Green, 1966 E+, 1K AK or 2K EP. Manually derusted steel (St 2 / PSt 2): HENSOGRUND 1K AK. Galvanised steel: HENSOGRUND WB Green or HENSOGRUND 2K.
-
2Check conditions for HENSOTHERM 471 KSMaterial, substrate and air at or above +5°C, relative humidity at or below 80%. Steel at least 5°C above dew point and not above +35°C. Application by trained professionals only.
-
3Stir HENSOTHERM 471 KSStir thoroughly with a slow agitator before use.
-
4Apply HENSOTHERM 471 KSAirless spray at 200 to 250 bar, nozzle 0.017 to 0.025 inch, output above 4 l/min, filters removed, thinned with max. 3% water. Or lambskin roller or long-bristled Chinex brush. Up to 1,000 g/m² per coat, first of several coats max. 700 g/m².
-
5Allow HENSOTHERM 471 KS to dry between coatsAt least 24 hours per coat at +20°C and 65% relative humidity. Overcoat only after a fingernail test and residual moisture below 5%.
-
6Top coat HENSOTHERM 471 KSWhere required, apply HENSOTOP WB Green, SB or 2K PU no earlier than 24 hours after the last coat, and only after a fingernail test.
Coverage Guide
Frequently Asked Questions
Can't find what you're looking for? Call us on 02920 026582 or use live chat for free expert advice.
HENSOTHERM 471 KS is a water-based intumescent coating for structural steel: I and H sections, circular and square hollow sections and box sections.
R15 to R180 for open and hollow sections.
It is approved in accordance with BS 476, Certifire No. CF 5344.
Up to 1,000 g/m² (approx. 500 µm dry) in a single coat. When building up in several coats, the first coat is max. 700 g/m² (approx. 350 µm dry).
At least 24 hours per coat at +20°C and 65% relative humidity. Overcoat only after a fingernail test and residual moisture below 5%.
On blasted steel: HENSOGRUND WB Green, HENSOGRUND 1966 E+, HENSOGRUND 1K AK or HENSOGRUND 2K EP. On manually derusted steel: HENSOGRUND 1K AK. On galvanised steel: HENSOGRUND WB Green or HENSOGRUND 2K.
A top coat is required where surfaces face environmental exposure or cleaning. It is not needed in dry indoor areas free of condensation. Compatible top coats are HENSOTOP WB Green, HENSOTOP SB and HENSOTOP 2K PU.
